項目
Properties |
Ni – Ti 合金
Ni – Tialloy |
Ni – Ti–Co 合金
Ni – Ti–Co alloy |
マルテンサイト相
(M相)
martensitick
phase |
引張強さ
Tensile strength |
MPa
(㎏f/m㎡) |
|
1175 ~ 1370
(120 ~ 140) |
1370 ~ 1570
(140 ~ 160) |
降伏強さ
Yield strength |
MPa
(㎏f/m㎡) |
|
~ 190
(~ 20) |
~ 294
(~ 30) |
|
~ 50 |
~ 50 |
横弾性係数
Horizontal modulus of elasticity |
MPa
(㎏f/m㎡) |
|
7845 ~ 9800
(800 ~ 1000) |
9800 ~ 13730
(1000 ~ 1400) |
オーステナイト相 (A相)
Austnitic
phase |
引張強さ
Tensile strength |
MPa
(㎏f/m㎡) |
|
1075 ~ 1175
(110 ~ 120) |
1275 ~ 1370
(130 ~ 140) |
降伏強さ
Yield strength |
MPa
(㎏f/m㎡) |
|
390 ~ 785
(40 ~ 80) |
490 ~ 980
(50 ~ 100) |
|
~ 20 |
~ 20 |
横弾性係数
Horizontal modulus of elasticity |
MPa
(㎏f/m㎡) |
|
17650 ~ 21575
(1800 ~ 2200) |
25500 ~ 28400
(2600 ~ 2900) |
